Product Description

HTC-8016, HTC-11001, HTC-10001, HTC-8711

STEPPED ANGLE PLATE HTC - 8711

Made from EN 31 steel.
Hardened & ground.
Tapped Holes for clamping jobs in any position.
Stepped construction.
Flatness and squareness to with in 0.002 per 6.
Sizes
- HTC- 8711 A 3X3X3 IN INCHES
- 75X75X75X IN MM.
- HTC - 8711 B 4X4X4 IN INCHES
- 100X100X100 IN MM.

ADJUSTABLE ANGEL PLATES (C.I) HTC 11001
Table surface is ground, 0 900 range (450 each way) graduated in degrees, machined T Slots.

#	Sizes Inch	Sizes MM	Height Inch	Height MM	App. Wt.
HTC -11001A	5X7	125X175	3-3/4	95	20 LBS
HTC - 11001B	7X10	175X250	5	125	44 LBS
HTC- 11001C	10X15	250X375	6-1/2	162	90 LBS

SINGLE POINT DIAMOND DRESSERS

In plain cylindrical shank size 1/2"X 6 long.

#	Carat Sizes
HTC 8016	0.16
HTC 8025	0.25
HTC 8035	0.35
HTC 8050	0.50
HTC 8075	0.75
HTC 8100	1.00
HTC 8125	1.25
HTC 8150	1.50
HTC 8175	1.75
HTC 8200	2.00
HTC 8250	2.50
HTC 8300	3.00
HTC 8350	3.50
HTC 8400	4.00
HTC 8500	5.00

EMERY WHEEL DRESSER H TC 10001(HUNTINGTON TYPE)

STURDY CONSTRUCTION.
MADE OF CAST IRON.

HTC 10001 A NO. 0
For wheels upto 10 Dia X 2

HTC 10001 B NO. 1
For Wheels upto 15 Dia X 3

HTC 10001 C NO. 2
For highest sizes Wheels.

REPLACEMENT CUTTERS H TC - 10002

HTC-10002 A
SPARE CUTTER FOR NO. 0 DRESSER

HTC 10002 B
SPARE CUTTER FOR NO. 1 DRESSER

HTC-10002 C
SPARE CUTTER FOR NO. 2 DRESSER
