Pp Monoblock Pumps Specification

Head Size
6-24 Meter

Flow Rate
200 LPM

Theory
Centrifugal Pump

Max Suction
7 Meter

Working Temperature
Up to 60C

Mounting Type
Foot Mounted

Discharge Pressure
1.5-2.5 Bar

Caliber
25 mm

Control System
Manual On/Off

Frequency
50 Hz

Features
Corrosion resistant, Light weight, Low maintenance

Inlet/Outlet
25 mm x 25 mm

Voltage
220-240 V AC

Noise Level
Below 75 dB

Speed
2900 RPM

Material
Polypropylene (PP)

Structure
Monoblock

Power
0.5 HP to 2 HP

Fuel Type
Electric Powered

Pressure
Up to 2.5 Bar

Usage
Chemical transfer, Water transfer

Application
Chemical Industries, Plating, Water Treatment, Fertilizer Industries

Suction Type
Single Suction

Seals Type
Mechanical Seal

Priming
Self Priming

Pump Type
Monoblock Pump

Capacity
1 to 5 m/h

Insulation Class
Class F

Motor Protection
IP55

Shaft Material
Stainless Steel 304

Impeller Type
Semi Open

Service
Continuous Duty (S1)

Color
Blue & Black

Connection Type
Threaded

About Pp Monoblock Pumps

Application: Chemical processing and transfer Water treatment and purification Pharmaceutical and biotech industries Food and beverage processing Pulp and paper industries Electro-Plating & Descaling Mining and wastewater treatment Scrubbing of Corrosive Gases. Like Ci2 Br2 F2 S02 S03 C02 Nh3 etc.

Robust Construction for Demanding Applications

Built from corrosion-resistant polypropylene and equipped with a stainless steel 304 shaft, these monoblock pumps withstand harsh chemical and water environments. The semi-open impeller design enhances efficiency for both chemical and water transfer. Their light weight and IP55 protection ensure dependable use in diverse industrial sites.

Reliable Operation and Flexible Integration

With a throughput of up to 200 liters per minute and a head of 6 to 24 meters, the pumps are ideal for a variety of applications. Foot-mounted and threaded for easy installation, they provide continuous (S1) service and low maintenance requirements, fully supporting seamless processes in chemical, plating, and water treatment facilities.

FAQ's of Pp Monoblock Pumps:

Q: How does the semi-open impeller benefit pump operation in chemical transfer applications?

A: The semi-open impeller enhances the handling of liquids containing small solids and reduces clogging risk, which is crucial for efficient chemical transfer. It also supports consistent flow even with slightly contaminated fluids.

Q: What safety and protection features are included in the pump?

A: The pump has an IP55-rated motor for protection against dust and water, a robust mechanical seal to prevent leakage, and insulation class F, ensuring safe and continuous operation in industrial environments.

Q: When should you select a PP Monoblock Pump for your process?

A: Choose this pump when you require chemical and water transfer involving corrosive fluids, need self-priming ability, and operate in conditions up to 60C. It is most suitable for industries like chemical processing, water treatment, and fertilizer production.

Q: Where can these pumps be installed and in what industries are they commonly used?

A: These pumps are suitable for installation in chemical plants, electroplating units, water treatment facilities, and fertilizer industries. Their corrosion resistance and ease of installation make them adaptable to various industrial settings across India.

Q: What are the usage benefits of using a PP Monoblock Pump?

A: PP Monoblock Pumps offer high flow rates, continuous duty operation, and resistance to most chemicals, ensuring long service life and reduced downtime. Their light weight and simple design facilitate easy maintenance and handling.

Q: How can the pump be controlled and what is its maintenance process?

A: The pump uses a manual on/off control system, supporting straightforward operation. Maintenance is minimal thanks to its simple structure, corrosion-resistant materials, and the reliability of the mechanical seal.
